| Product Type | Mainboard |
| Brand | NZXT |
| Model | N7 Z790 |
| Socket | 1700 (12th Gen – Alder Lake) , 1700 (13th Gen – Raptor Lake) , 1700 (14th Gen – Raptor Lake Refresh) |
| Wattage | 150W |
| Chipset | Intel Z790 |
| Series | Celeron , Core i3 , Core i5 , Core i7 , Core i9 , Pentium |
| Slot | 4 |
| Memory Type | DDR5 |
| Max. Capacity | 128 GB |
| Speed | 4800 , 5200 , 5200 (OC) , 5600 (OC) , 6000 (OC) , 6400 (OC) |
| Graphic | Integrated Graphics Processor (Depends on CPU) |
| Audio | Realtek ALC1220 |
| Audio Detail | 8-Channel high-definition audio |
| SATA 2 | – Port |
| SATA 3 | 4 Port |
| RAID | RAID 0, 1, 10 for NVMe Storage RAID 0, 1, 10 for SATA Storage |
| M.2 | 3 x M.2 Connector(s) — CPU • 1 x M.2_1 Type 2242/2260/2280 (PCIe 4.0 ×4 mode) — Chipset • 1 x M.2_2 Type 2242/2260/2280/22110 (PCIe 4.0 ×4 mode) • 1 x M.2_3 Type 2242/2260/2280 (PCIe 4.0 ×4 & SATA 6Gb/s mode) Port |
| Details | No |
| Slot | 1 x PCIe 5.0 x16 Slot , 2 x PCIe 3.0 x1 Slots , 2 x PCIe 4.0 x16 Slot |
| LAN | Realtek RTL8125BG |
| LAN Speed | 100/1000/2500 Mbps |
| Wireless | Wi-Fi 6E (802.11ax) Bluetooth 5.2 |
| USB 2.0 | 2 Port |
| USB 3.0 | – Port |
| USB 3.1 | – Port |
| Serial | – Port |
| USB 3.2 | 1 x USB 3.2 Gen 2×2 Type-C 2 x USB 3.2 Gen 2 Type-A 3 x USB 3.2 Gen 1 Type-A Port |
| D-Sub (VGA) | – Port |
| DVI | – Port |
| HDMI | 1 Port |
| DisplayPort | – Port |
| Audio | 5 x Audio Jacks 1 x Optical S/PDIF Out Port |
| PS/2 | No |
| Additional | No |
| LAN | 1 Port |
| Form Factor | ATX |
| Power Connector | 24 + 4 + 8 Pin |
| Dimension | – cm |
| การรับประกัน | 3 Years |
