MAINBOARD (เมนบอร์ด) MSI Z790 GAMING PLUS WIFI (SOCKET LGA 1700 DDR5 ATX)

฿7,700.00

ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม

ติดต่อสอบถามราคาพิเศษ

Line : @greatocean
Tel : 099-495-8880
Facebook : https://www.facebook.com/gtoengineer/
Email : support@gtoengineer.com

SKU: 1007000017 Category: Brand:
Description
Product Type Mainboard
Brand MSI
Model Z790 GAMING PLUS WIFI
Socket 1700 (12th Gen – Alder Lake) , 1700 (13th Gen – Raptor Lake) , 1700 (14th Gen – Raptor Lake Refresh)
Wattage 150W
Chipset Intel Z790
Series Celeron , Core i3 , Core i5 , Core i7 , Core i9 , Pentium
Slot 4
Memory Type DDR5
Max. Capacity 192 GB
Speed 4800 , 5000 , 5000 (OC) , 5200 , 5200 (OC) , 5400 , 5400 (OC) , 5600 , 5600 (OC) , 5800 (OC) , 6000 (OC) , 6200 (OC) , 6400 (OC) , 6600 (OC) , 7000 (OC) , 7200 (OC)
Graphic Requires a CPU with Integrated Graphics.

• 1 x HDMI Support HDMI 2.1 HDR, maximum resolution of 4K 60Hz*
• 1 x DisplayPort Support DP 1.4, maximum resolution of 4K 60Hz*

*Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
Audio Realtek ALC897
Audio Detail 7.1-Channel High Definition Audio
SATA 2 – Port
SATA 3 6 Port
RAID RAID 0, RAID 1, RAID 5, RAID 10 for SATA storage devices
RAID 0, RAID 1, RAID 5, RAID 10 for PCIe / NVMe storage devices
M.2 4x M.2 slots (Key M)

• M2_1 slot (From CPU) Supports up to PCIe 4.0 x4 2242/ 2260/ 2280/ 22110 storage devices
• M2_2 slot (From Z790 chipset) Supports up to PCIe 4.0 x4 2242/ 2260/ 2280 storage devices
• M2_3 slot (From Z790 chipset) Supports up to PCIe 4.0 x4 & SATA 6Gb/s 2242/ 2260/ 2280 storage devices
• M2_4 slot (From Z790 chipset) Supports up to PCIe 4.0 x4 & SATA 6Gb/s 2242/ 2260/ 2280 storage device Port
Details • 3 x PCIe x16 slots
– PCI_E1 slot (From CPU) Supports up to PCIe 5.0 x16
– PCI_E3 & PCI_E4 slots (From Z790 chipset) PCI_E3 supports up to PCIe 4.0 x4 PCI_E4 supports up to PCIe 3.0 x1

• 1 x PCIe x1 slot (From Z790 chipset)
– PCI_E2 supports up to PCIe 3.0 x1
Slot 1 x PCIe 3.0 x1 Slot , 1 x PCIe 3.0 x16 Slot , 1 x PCIe 4.0 x16 Slot , 1 x PCIe 5.0 x16 Slot
LAN Intel 2.5Gb Ethernet
LAN Speed 100/1000/2500 Mbps
Wireless Intel Wi-Fi 6E
– The Wireless module is pre-installed in the M.2 (Key-E) slot
– Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (160MHz) up to 2.4Gbps
– Supports 802.11 a/ b/ g/ n/ ac/ ax
– Supports Bluetooth 5.3**, FIPS, FISMA

*The usage of Wi-Fi 6GHz band relies on Windows 11 support and depends on every country’s regulations.
** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details
USB 2.0 4 Port
USB 3.0 – Port
USB 3.1 – Port
Serial – Port
USB 3.2 2 x USB 3.2 Gen 1 5Gbps Type-A
1 x USB 3.2 Gen 2 10Gbps Type-A
1 x USB 3.2 Gen 2×2 20Gbps Type-C Port
D-Sub (VGA) – Port
DVI – Port
HDMI 1 Port
DisplayPort 1 Port
Audio 6 Port
PS/2 1 (Keyboard/Mouse combo) Port
Additional 1 x Flash BIOS button
2 x Wi-Fi Antenna connectors
LAN 1 Port
Form Factor ATX
Power Connector 24 + 8 + 8 Pin
Dimension 30.5 x 24.4 cm
การรับประกัน 3 Years
Additional information
Product Type

Mainboard

Brand

MSI

Model

Z790 GAMING PLUS WIFI
