MSI

MAINBOARD (เมนบอร์ด) MSI MPG Z790I EDGE WIFI (SOCKET LGA 1700 DDR5 MINI-ITX)

รหัสสินค้า : 1007000034

฿13,500

โทรสอบถามราคา

การรับประกัน :

Data Sheet :

1007000034_datasheet.pdf

ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม

ติดต่อสอบถามราคาพิเศษ

Line :
Tel : 099-495-8880
Facebook : https://www.facebook.com/gtoengineer/
Email : support@gtoengineer.com

อัปเดตล่าสุด : 1 year ago

Product Type	Mainboard
Brand	MSI
Model	MPG Z790I EDGE WIFI
Socket	1700 (12th Gen – Alder Lake) , 1700 (13th Gen – Raptor Lake) , 1700 (14th Gen – Raptor Lake Refresh)
Wattage	150W
Chipset	Intel Z790
Series	Celeron , Core i3 , Core i5 , Core i7 , Core i9 , Pentium
Slot	2
Memory Type	DDR5
Max. Capacity	96 GB
Speed	4800 , 5000 , 5000 (OC) , 5200 , 5200 (OC) , 5400 , 5400 (OC) , 5600 , 5600 (OC) , 5800 (OC) , 6000 (OC) , 6200 (OC) , 6400 (OC) , 6600 (OC) , 7000 (OC) , 7200 (OC) , 7400 (OC) , 7600 (OC) , 7800 (OC) , 8000 (OC)
Graphic	Requires a CPU with Integrated Graphics. — • 1 x DisplayPort 1.4 port, supporting a maximum resolution of 4K 60Hz/* • 1 x HDMI 2.1 port with HDR, supporting a maximum resolution of 4K 60Hz/ * — Available only on processors featuring integrated graphics. * Graphics specifications may vary depending on the CPU installed
Audio	Realtek ALC4080
Audio Detail	• 7.1-Channel USB High Performance Audio • Supports up to 32-Bit/384 kHz playback on front panel
SATA 2	– Port
SATA 3	4 Port
RAID	• Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices • Supports RAID 0, RAID 1, RAID 5 for M.2 NVMe storage devices
M.2	3 x M.2 slots (Key M) — • M2_1 slot (From CPU) – Supports up to PCIe 4.0 x4 – Supports 2280 storage devices — • M2_2 slot (From Z790 chipset) – Supports up to PCIe 3.0 x4 – Supports up to SATA 6Gb/s – Supports 2280 storage devices — • M2_3 slots (From Z790 chipset) – Supports up to PCIe 4.0 x4 – Supports 2280 storage devices Port
Details	1 x PCIe 5.0 x16 slot (From CPU)
Slot	1 x PCIe 5.0 x16 Slot
LAN	Intel 2.5Gb Ethernet
LAN Speed	100/1000/2500 Mbps
Wireless	Intel Wi-Fi 6E • The Wireless module is pre-installed in the M.2 (Key-E) slot • Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (160MHz) up to 2.4Gbps • Supports 802.11 a/ b/ g/ n/ ac/ ax • Supports Bluetooth 5.3*, FIPS, FISMA — The usage of Wi-Fi 6GHz band relies on Windows 11 support and depends on every country’s regulations. ** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details.
USB 2.0	– Port
USB 3.0	– Port
USB 3.1	– Port
Serial	– Port
USB 3.2	4 x USB 3.2 Gen 1 5Gbps Type-A 2 x USB 3.2 Gen 2 10Gbps Type-A 1 x USB 3.2 Gen 2×2 20G Type-C Port
D-Sub (VGA)	– Port
DVI	– Port
HDMI	1 Port
DisplayPort	1 Port
Audio	3 Port
PS/2	No
Additional	1 x Clear CMOS button 2 x Wi-Fi Antenna connectors
LAN	1 Port
Form Factor	Mini-ITX
Power Connector	24 + 8 Pin
Dimension	17.0 x 17.0 cm
การรับประกัน	3 Years
