| Product Type | Server |
| BRAND | ATLOS |
| Model | Altos BrainSphere™ R320F5 |
| Factor | Rack |
| PROCESSOR | Intel |
| CPU | Intel® Xeon® E-2224 Processor 8M Cache, 3.40 GHz |
| Memory | 16GB (1x16GB) DDR4-2666 ECC UDIMM |
| Expansion Slots | 1 PCI-E 3.0 x8 1 M.2 2280/22110 slot (M-key, w/PCIe 3.0 x4) |
| Harddisk | 2 x 1TB 3.5″ SATA 7200 RPM |
| Chipset | Intel® C242 |
| RAID Controller | Integrated SATA RAID supports RAID 0, 1, 5, 10 on Windows® OS only |
| Processor Graphics | N/A |
| Max Internal Disks supports | 4 x 3.5” SAS/SATA hot-swappable bays for HDD/SSD |
| Optical device | No |
| Onboard Gigabit Ethernet | 2 x RJ45 Ethernet LAN ports |
| Redundant Power Supply | Yes (300W) |
| Form Factor | Rack |
| OS Support (Not Provide OS) | Microsoft® Windows Server® 2019 Red Hat® Enterprise Linux® |
| Mouse | Altos USB Mouse |
| Keyboard | Altos USB Keyboard |
| Warranty | 3 Year warranty Part & Labor, 5×8, Onsite Sevice NBD Thailand |
| Model | Altos BrainSphere™ R320F5 |
|---|---|
| CPU | Intel® Xeon® E-2224 Processor 8M Cache, 3.40 GHz |
| Memory | 16GB (1x16GB) DDR4-2666 ECC UDIMM |
| Expansion Slots | 1 PCI-E 3.0 x8 1 M.2 2280/22110 slot (M-key, w/PCIe 3.0 x4) |
| Harddisk | 2 x 1TB 3.5" SATA 7200 RPM |
| Chipset | Intel® C242 |
| RAID Controller | Integrated SATA RAID supports RAID 0, 1, 5, 10 on Windows® OS only |
| Processor Graphics | |
| Max Internal Disks supports | 4 x 3.5” SAS/SATA hot-swappable bays for HDD/SSD |
| Optical device | No |
| Onboard Gigabit Ethernet | 2 x RJ45 Ethernet LAN ports |
| Redundant Power Supply | Yes (300W) |
| Form Factor | Rack |
| OS Support (Not Provide OS) | Microsoft® Windows Server® 2019 Red Hat® Enterprise Linux® |
| Mouse | Altos USB Mouse |
| Keyboard | Altos USB Keyboard |
| Warranty | 3 Year warranty Part & Labor, 5×8, Onsite Sevice NBD Thailand |
