| Product Type | Workstation |
| BRAND | ATLOS |
| Model | Altos P130 F9 |
| Factor | Tower |
| PROCESSOR | Intel |
| CPU | CPU Intel® Core™ i5-13500 Processor , 24M Cache, up to 4.80 GHz |
| Memory | 16GB (1x16GB) DDR5-4800 Non-ECC UDIMM |
| Expansion Slots | 1 x PCI-E 4.0 x16 slot 1 x PCI-E 3.0 x16 slot (x4 Lanes) 1 x PCI-E 3.0 x1 slot 1 x PCI slot 2 x M.2 2280 PCI-E 4.0 slots (For SSD) 1 x M.2 2230 PCI-E 3.0, E Key for Wi-Fi & Bluetooth |
| Harddisk | 1 x M.2 1TB PCIe4.0x4 NVMe |
| Chipset | Intel® W680 Chipset |
| RAID Controller | Intel onboard software RAID 0, 1, 5, 10 (only supports Windows OS) |
| Processor Graphics | Intel® UHD Graphics 700 series |
| Max Internal Disks supports | 2 x 3.5″ slots For hard disks |
| Optical device | Optional |
| Onboard Gigabit Ethernet | 1 Gb/s (10/100/1000) BASE-T LAN Port (Intel® I219-LM, support Intel vPro®) 2.5 Gb/s (10/100/1000) BASE-T LAN Port (Intel® I226-V) |
| Redundant Power Supply | 500W Single, 80PLUS® Gold |
| Form Factor | Tower |
| OS Support (Not Provide OS) | Microsoft® Windows 10/11 Pro 64-bit UEFI Shell |
| Mouse | USB Mouse |
| Keyboard | USB Keyboard |
| Warranty | 3 Year warranty Part & Labor, 5×8, Onsite Sevice NBD Thailand |
| Model | Altos P130 F9 |
|---|---|
| CPU | CPU Intel® Core™ i5-13500 Processor, 24M Cache, up to 4.80 GHz |
| Memory | 16GB (1x16GB) DDR5-4800 Non-ECC UDIMM |
| Expansion Slots | 1 x PCI-E 4.0 x16 slot 1 x PCI-E 3.0 x16 slot (x4 Lanes) 1 x PCI-E 3.0 x1 slot 1 x PCI slot 2 x M.2 2280 PCI-E 4.0 slots (For SSD) 1 x M.2 2230 PCI-E 3.0, E Key for Wi-Fi & Bluetooth |
| Harddisk | 1 x M.2 1TB PCIe4.0x4 NVMe |
| Chipset | Intel® W680 Chipset |
| RAID Controller | Intel onboard software RAID 0, 1, 5, 10 (only supports Windows OS) |
| Processor Graphics | Intel® UHD Graphics 700 series |
| Max Internal Disks supports | 2 x 3.5" slots For hard disks |
| Optical device | Optional |
| Onboard Gigabit Ethernet | 1 Gb/s (10/100/1000) BASE-T LAN Port (Intel® I219-LM, support Intel vPro®) 2.5 Gb/s (10/100/1000) BASE-T LAN Port (Intel® I226-V) |
| Redundant Power Supply | 500W Single, 80PLUS® Gold |
| Form Factor | Tower |
| OS Support (Not Provide OS) | Microsoft® Windows 10/11 Pro 64-bit UEFI Shell |
| Mouse | USB Mouse |
| Keyboard | USB Keyboard |
| Warranty | 3 Year warranty Part & Labor, 5×8, Onsite Sevice NBD Thailand |
