Product Specifications
Display
Diagonal Size	98″
Panel Type	VA
Resolution	3,840 x 2,160
Pixel Pitch (HxV)	0.5622 x 0.5622 (mm)
Brightness (Typ)	450 nit
Contrast Ratio	5,000:1
Viewing Angle (H/V)	178/178
Response Time	8ms
Color Gamut	DCI 93% (Typ.)
Glass Haze	2%
H-Scanning Frequency	30~81kHz
Maximum Pixel Frequency	594MHz
V-Scanning Frequency	48~75Hz
Contrast Ratio (Dynamic)	Mega
Operation Time Support	16/7
Connectivity
HDMI In	4
DP In	No
DVI In	N/A
Version of HDMI	2
Version of DP	N/A
Version of HDCP	2.2
Tuner In	N/A
USB	2
IR In	No
HDBaseT In	N/A
Audio In	No
Audio Out	N/A
Video Out	N/A
Power Out	N/A
RS232 In	Yes
RS232 Out	N/A
RJ45 In	Yes
RJ45 Out	N/A
WiFi	Yes
3G Dongle	N/A
Bluetooth	Yes
Power
Power Supply	AC100-240V 50/60Hz
Power Consumption (Off Mode)	N/A
Power Consumption (On Mode)	275 W
Power Consumption (Sleep Mode)	0.5 W
Dimension
Set Dimension (WxHxD)	2180.6 x 1243.9 x 48.4 mm
Package Dimension (WxHxD)	2379 x 1431 x 350 mm
Weight
Set Weight	56.3 kg
Package Weight	87.8 kg
Operation Conditions
Temperature	0℃~ 40℃
Humidity	10 ~ 80%, non-condensing
Mechanical Specification
VESA Mount	600 x 400 mm
Bezel Width	3 bezeless
Bezel Color	TITAN BLACK
Frame Material	Non-Glossy
Optional Feature
Mount	N/A
Stand	In box
SoC
OS Version	Tizen 6.5
Flash Memory Size	8GB
Eco
Energy Efficiency Class	N/A
Certification and Compliance
EMC	Class A
Safety	60950-1, 62368-1
